SANCASSIANO One Arm Elevator - Model ER1 OB

SANCASSIANO One Arm Elevator – Model ER1 OB

SERIES ER1-OB

Features: Oblique one arm elevator-tilter with screw lifting system, suitable up to the following bowls:
CP2, PLT300-C, SE250, BTE220, FRC160, GENESI 220 (see table)

Tilting action allowed through manual approval (presence of the operator required *) up to 1200 mm discharge height. Automatic tilting cycle with safety cage (according to the safety regulation in force) with stainless steel grid (from 1200 mm discharge height) ) – tilter elevated of the ground with no. 4 stainless steel feet. Single opening access door.

Description

Elevator-Tilter ER1-OB with discharge height up to 1200 mm.

Elevator-Tilter ER1-OB with discharge height up to 1700 mm.

Elevator-Tilter ER1-OB with discharge height up to 2400 mm.

Elevator-Tilter ER1-OB with discharge height up to 2800 mm.

Elevator-Tilter ER1-OB with discharge height up to 3200 mm.

MODEL / mm	MAXIMUM LIFTING CAPACITY
ER1-OB up to 2800 without automatic scraping system	CESE300 – CEBTE300 – CEFRC240 – CEPLT300 – CEPLT-C 300 – GCE220 – GCRE 330 – CP2 – CP3 (Confirm with technical dept).
ER1-OB up to 2800 with automatic scraping system	CESE250 – CEBTE220 – CEFRC240 – CEPLT-C 300 – NO PLT – GCE160 – GCRE 270. When discharging GCE220-GERE330 don’t exceed ER1-OB 1800 with automatic scraping system.
ER1-OB up to 3200 without automatic scraping system	CESE250 – CEBTE220 – CEFRC160 – CEPLT 300 – CEPLT-C300 – GCE160 – CERE 270 – CP2
ER1-OB up to 3200 with automatic scraping system	CESE250 – CEBTE220 – CEFRC160 – CEPLTC 300 – NO PLT – NO GENESI
